WOLF TOOTH Direct Mount chainring for Sram 8-Bolt Drop-Stop ST 3mm 30t

Product description

Optimized for SRAM Transmission mountain groupsets and T-Type chains, these chainrings are the perfect choice for riders who want a different number of teeth than the standard set-up offers, or who want to upgrade their drivetrain with a top-of-the-line, USA-made product with an optimized tooth profile for better performance.

Offset selection and chainline

• 3mm offset: Designed for SRAM mountain cranks with DUB WIDE bottom bracket, which already have the 55mm chainline required by SRAM T-Type Transmission groupsets.

Compatibility

• These chainrings replace the existing spider and chainring or direct mount chainrings on SRAM T-Type Transmission AXS cranks, SRAM Transmission 70 and 90 cranks, Cane Creek eeWings titanium cranks (8-bolt), and other models using the 8-bolt mounting standard.

Main advantages

• Tooth profile: Patented Drop-Stop® B profile of alternating wide and narrow teeth for maximum chain retention and excellent mud clearance.
• Available versions: 3 mm and 0 mm offset variants.
• 55mm chainline: Available with 3mm offset for DUB Wide, or 0mm offset for standard DUB.
• 52mm chainline: Available with 3mm offset for standard DUB axle.

Recommendation

• For maximum chain security, we recommend using a derailleur with a clutch.
• Installation: Use the special T20 screws included. Tightening torque 4 Nm (requires T20 wrench).

Technical specifications

• Weights: 30z (65g) | 32z (69g) | 34z (73g) | 36oz (77g)
• Material: High-strength aluminum 7075-T6
• Package contents: Set of eight special stainless steel T20 screws
• Origin: Made in USA
